SMART-SL

Smart Series Street Light

LoRaWAN + 2.4G MESH connected smart street light

The Smart Series is Jupiter Made-Well's IoT-enabled street light, combining >175 lm/W Gree/Lumileds/OSRAM LEDs with a LoRaWAN and 2.4G MESH dual-mode wireless controller. Remote dimming, fault reporting, and scheduled on/off programmes are managed from a cloud dashboard. The MEAN WELL XLG IP67 isolated driver carries a 5-year warranty and supports 0–10 V dimming. Power range 100–240 W, 20 KV surge protection, IP65, system lifespan >10 years.

Power
  • LoRaWAN + 2.4G MESH Dual Wireless
  • Remote Dimming & Fault Reporting
  • >175 lm/W LED Efficiency
  • 20 KV Surge Protection
  • MEAN WELL XLG IP67 Driver
Request a QuoteView All Products

Technical Highlights

Specifications — 100W

Rated Power100W
Efficacy>175 lm/W
LED Source3030 high-lumen (Cree/Lumileds/OSRAM)
Surge Protection20KV
CommunicationLoRaWAN + 2.4G MESH dual-mode
DriverMEAN WELL XLG IP67 with 0–10V dimming (5-yr warranty)
ProtectionIP65
System Life>10 years
Warranty5 years
