SMART-SL
Smart Series Street Light
LoRaWAN + 2.4G MESH connected smart street light
The Smart Series is Jupiter Made-Well's IoT-enabled street light, combining >175 lm/W Gree/Lumileds/OSRAM LEDs with a LoRaWAN and 2.4G MESH dual-mode wireless controller. Remote dimming, fault reporting, and scheduled on/off programmes are managed from a cloud dashboard. The MEAN WELL XLG IP67 isolated driver carries a 5-year warranty and supports 0–10 V dimming. Power range 100–240 W, 20 KV surge protection, IP65, system lifespan >10 years.
- LoRaWAN + 2.4G MESH Dual Wireless
- Remote Dimming & Fault Reporting
- >175 lm/W LED Efficiency
- 20 KV Surge Protection
- MEAN WELL XLG IP67 Driver
Technical Highlights
Specifications
SeriesSmart Series
Power Range100–240 W
LED SourceGree / Lumileds / OSRAM 3030
Luminous Efficacy>175 lm/W
CommunicationLoRaWAN + 2.4G MESH
Surge Protection20 KV
IP RatingIP65
DriverMEAN WELL XLG IP67, 0–10 V dimming
System Life>10 Years
Warranty5 Years
CertificationsCE, RoHS
